GSHZ Mechanical Fine Bar Screen
The equipment is a special rake teeth made of ABS engineering plastics, nylon or stainless steel, which are installed on the rake teeth shaft in a certain order to form a closed rake teeth chain.
Keywords:
Category:
Mechanical Screen
Product description
The equipment is a special rake teeth made of ABS engineering plastics, nylon or stainless steel, which are installed on the rake teeth shaft in a certain order to form a closed rake teeth chain, and its lower part is installed in the inlet channel water. When the drive system drives the chain wheel to rotate at a constant speed, the whole rake gear chain will move from top to bottom, and carry solid debris to separate from the liquid. The fluid will flow out through the rake gear clearance, and the whole working state is continuous.
Due to the special structure and shape of the rake teeth, when the rake teeth chain carries debris to the upper end for reverse movement, the relative self-cleaning movement is generated between the front and rear rake, so that the debris falls off by gravity. A rotating cleaning brush can be set at the back of the equipment to further remove the dirt retained in the rake teeth. If it is necessary to order, it shall be noted.
Scope of Application
GSHZ rotary grille cleaner (also known as "solid-liquid separator") is widely used in urban sewage treatment plants, water plants, pump stations and power plant intakes to automatically intercept and remove floating debris in water and ensure normal operation of the next process; It can also be used for solid-liquid separation in textile, printing and dyeing, abattoir, leather making, papermaking, sugar making, brewing and food processing.
Product Parameters
Technical parameter | Equipment model | 300 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | 1100 | 1200 | 1300 | 1400 | 1500 |
Width of equipment(B) | 300 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | 1100 | 1200 | 1300 | 1400 | 1500 | |
Effective gate width (B2) | B2=B-160 | |||||||||||||
Total width of equipment(B3) | 3B=B+350 | |||||||||||||
Effective gate gap | 2、3、5、10、20、30、40、50 | |||||||||||||
Rake chain speed | about2m/min a | |||||||||||||
Motor power KW | 0.37~0.75 | 0.55~1.1 | 0.75~1.5 | 1.1~2.2 | 1.5~3 | |||||||||
Mounting dimensions | Mounting angle α | 60°、65°、70°、75°、80° | ||||||||||||
Width of channelB1 | B1≧B+70 | |||||||||||||
Depth of channel H | 500~15000 | |||||||||||||
Slag discharge height h | 400~1500 Normal as per 600 | |||||||||||||
Structure diagram
Water flow meter
model：GSHZ | 300 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | 1100 | 1200 | 1250 | 1500 | ||
Water level in front of gate m | 1 | |||||||||||||
Flow velocity of fluid m/s | 0.5 ~ 1.0 | |||||||||||||
Rake tooth clearance(mm) | 1 | Water flow rate(t/d) | 1850-3700 | 2080-4160 | 2900-5800 | 3700-7400 | 4500-9000 | 5300-10600 | 6000-12000 | 7000-14000 | 7800-15600 | 8600-17200 | 9000-18000 | 11000-22000 |
3 | 3700-7400 | 4100-8200 | 5700-14400 | 7500-15000 | 9000-18000 | 10600-21200 | 12300-24600 | 14000-28000 | 15500-31000 | 17200-34400 | 18000-36000 | 22000-44000 | ||
5 | 4500-9000 | 5200-10400 | 7100-14200 | 9200-18400 | 11200-22400 | 13000-26000 | 15000-30000 | 17400-34800 | 19400-38800 | 21000-42000 | 22500-45000 | 24000-48000 | ||
10 | 5300-10600 | 6200-12300 | 8800-17600 | 11000-22000 | 13500-27000 | 16000-32000 | 17400-34800 | 21100-42200 | 24000-48000 | 25000-50000 | 26000-52000 | 27000-54000 | ||
20 | 5500-11000 | 6650-13000 | 9000-18000 | 11500-23000 | 14000-28000 | 17000-34000 | 19000-38000 | 22000-44000 | 25000-50000 | 27000-54000 | 28000-56000 | 29000-58000 | ||
30 | 7100-14200 | 8600-17200 | 11700-23400 | 14900-29800 | 18200-36400 | 22100-44200 | 24700-49400 | 28600-57200 | 32500-65000 | 35100-70200 | 36400-72800 | 37700-75400 | ||
40 | 7800-15500 | 10200-20500 | 14500-29000 | 18800-37500 | 23000-46000 | 27000-54000 | 31500-63000 | 36000-72000 | 40000-80000 | 44000-88000 | 46000-92000 | 57000-115000 | ||
50 | 10200-20400 | 13250-26500 | 18850-37700 | 24450-48900 | 29900-59800 | 35100-70200 | 40950-41900 | 46800-93600 | 52000-104000 | 57200-114400 | 59800-119600 | 47100-148200 | ||
