Pump Station
Prefabrication pump station, also known as integrated prefabrication pump station, is divided into lift pump station and sewage treatment pump station.
Keywords:
Category:
Pump Station
Product description
Prefabrication pump station, also known as integrated prefabrication pump station, is divided into lift pump station and sewage treatment pump station. Its function is to collect rainwater and sewage from urban pipelines. After being mixed with sludge and large impurities through fences and centrifugal pumps, the sewage can be quickly transported to the sewage treatment plant without blocking. Solve the problem that the pipeline water cannot flow from the ground to the highland due to the terrain and the low-lying land in the city is easy to accumulate water and waterlogged. It is used to improve and convey the sewage volume, characterized by integration, intelligence, energy conservation, corrosion resistance, less one-time investment, low maintenance cost, etc.
The prefabricated pump station can be divided into GRP integrated prefabricated pump station and stainless steel integrated prefabricated pump station according to different cylinder materials.
Generally, prefabricated pump station is a prefabricated sewage lift pump station with FRP as the cylinder. Equipment assembly can be completed in the factory, and finished products can be transported to the project site for hoisting in the prefabricated foundation pit.
Prefabricated pump station is made of high-strength FRP cylinder as outer cylinder, and the inner part is composed of sewage pump, self-coupling device, multiple pipeline valves, crushing grid, water inlet and outlet, flange and control box.
Range of Application
1. Collection and transportation of sewage in living quarters or rural communities
2. Collection and transportation of sewage from urban sewage treatment plants
3. Collection and transportation of rainwater in low-lying urban areas
4. Construction and renovation of municipal sewage pipe network
5. Renovation and expansion of the old pumping station
6. Water circulation of lakes
Introduction to Structure
The prefabricated pump station has standard integrated rainwater collection, sewage treatment and transportation solutions. It is composed of main components of shaft, submersible sewage pump, fence, control system, remote control system, automatic cleaning base and water pump.
Product Parameters
Type | Cylinder diameter (mm) | Cylinder height (m) | Inlet flow rate (m³/d) | Number of pumps |
Small pumping station | 1000 | 1.2/3 | 1000 | 1 / 2 |
1200 | ≤6 | 2000 | 1 / 2 | |
1500 | ≤12 | 6000 | 1 / 2 | |
Medium and large pumping stations | 2000 | ≤12 | 10000 | 2 / 3 |
3000 | ≤12 | 35000 | 2/3/4 | |
3800 | ≤12 | 86000 | 2/3/4 | |
Non-standard customization | ≤16 | 100000 | 2/3/4 |
